2060mpa High Tensile Bead Wire
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Breaking Force (Mpa): | 2060mpa | Diameter(mm): | 1.65mmHT |
|---|---|---|---|
| Product Name: | High Tensile Bead Wire | Type: | Tyre Steel Wire |
| Feature: | High Tensile Strength | OEM/DOM: | Yes |
| Highlight: | High Tensile Bead Wire,High Tensile Steel Wire |
||
steel belt High Tensile Bead Wire 2060mpa
2060mpa high tensile strength
Coil with Six steel belts fixed
6000MT monthly production
Descrition:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
Steel grade:70#,72#,80#,82#
Standard: AISI,ASTM,GB,JIS
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ 1.65mmHT |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.65± 0.02 |
1.63-1.67 |
|||
|
Breaking force (Mpa) |
≥2050 |
2050-2150 |
|||
|
Elongation at break(%) |
≥5.0 |
5.0-6.0 |
|||
|
Yield ratio(%) |
≥85 |
85.4-87.6 |
|||
|
Torsion(360°/100d) |
≥25 |
29-35 |
|||
|
Bronze coated(g/kg) |
0.20-0.40 |
0.32-0.36 |
|||
|
Sn (%) |
0.3-3.0 |
1.7 |
|||
|
Cu(%) |
≥97 |
98.3 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
