Tire Steel High Tensile Bead Wire
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Diameter(mm): | Φ 1.8mmHT | Product Name: | High Tensile Bead Wire |
|---|---|---|---|
| Type: | Tyre Steel Wire | Feature: | Elongation At Break (6.0%) |
| Automatic Computer Control System: | Yes | OEM/ODM: | Yes |
Tire Steel High Tensile Bead Wire
Elongation at break (6.0%)
Automatic computer control system
specialization product line
Descrition:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ 1.8mmHT |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.8± 0.02 |
1.78-1.82 |
|||
|
Breaking force (Mpa) |
≥2050 |
2050-2200 |
|||
|
Elongation at break(%) |
≥5.0 |
5.0-6.0 |
|||
|
Yield ratio(%) |
≥85 |
85.4-87.6 |
|||
|
Torsion(360°/100d) |
≥25 |
29-35 |
|||
|
Bronze coated(g/kg) |
0.20-0.40 |
0.32-0.36 |
|||
|
Sn (%) |
0.3-3.0 |
1.7 |
|||
|
Cu(%) |
≥97 |
98.3 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
