Home ProductsTire Bead Wire

Bronze Coated Tire Bead Wire Tensile High , 2230Mpa Tyre High Carbon Wire Durable

I'm Online Chat Now
Certification
China Zhangjiagang City Shengda Steel Wire Rope Co.,Ltd. certification
China Zhangjiagang City Shengda Steel Wire Rope Co.,Ltd. certification
1.Excellent quality, competitive price, good service, timely delivery; 2. No customer complaints

—— Deestone Limited

Bronze Coated Tire Bead Wire Tensile High , 2230Mpa Tyre High Carbon Wire Durable

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Bronze Coated Tire Bead Wire Tensile High , 2230Mpa Tyre High Carbon Wire Durable Get Best Price

Product Details:
Place of Origin: China
Brand Name: Shengda
Certification: ISO9001 , GB/T14450- 2008
Model Number: 0.95mmHT
standard: AISI,ASTM,GB,JIS
application: maufacturing
steel grade: 70#,72#,80#,82#
Payment & Shipping Terms:
Minimum Order Quantity: 20 MT
Price: free sample
Packaging Details: Z2 350-420kgs/coil with plastic in one box on pallet ,in container
Delivery Time: With 20 days after confirmed purchase order
Payment Terms: L/C at sight ,T/T in advance,D/P at sight
Supply Ability: Monthly 6000 Mt
Detailed Product Description
Diameter(mm): Φ0.95 Elongation At Break (%): 8.5-9.2
Surface Quality: Coating Smooth And Uniform Tensile(Mpa): 2150-2230
Torsion(360°/200d): 31-42 Yield Ratio: 93.4-94.9
Application: Bike, Bicycle, Automobiles, Motorcycles, Planes, Vehicles Feature: Normal Tensile, Rustproof, Durable, Waterproof, Bronze Coated
High Light:

tyre bead wire

,

mild steel wire

,

copper clad steel wire

Bronze Coated Tire Bead Wire Tensile High , 2230Mpa Tyre High Carbon Wire Durable



  • High tensile 2230 mpa
  • Inside the waterproof packing
  • 6000MT monthly production
  • Standard AISI,ASTM,GB,JIS
  • steel grade 70# ,72# ,80# ,82#





Description:



Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.







Applications



  • Reinforcement of all types of tyres such as trucks, buses, cars, motorcycles,    bicycles etc.
  •  use in  rubber



Our range of Tyre Bead Steel Wire includes:


  • Normal Tensile: 0.78 mm, 0.89 mm, .0.95mm 0.965 mm, 1.55mm1.65 mm,1.8mm 2.0 mm, 2.2 mm
  • High Tensile:0.78mmHT 0.89 mmHT, 0.95 mmHT, 0.965mmHT1.295 mmHT, 1.40 mmHT, 1.55 mmHT, 1.60 mmHT, 1.83 mmHT





Specifications:



Description

BEAD  WIRE

Reference

GB/T14450- 2008

Diameter

Φ0.95mmHT

Item

Standard

Result

Diameter(mm)

0.94-0.97

0.94-0.96

Straightness

≤400

120-400

Yield ratio

92.0-95.0

93.4-94.9

Tensile(Mpa)

≥2100

2150-2230

Elongation(%)

≥5

8.5-9.2

Torsion(360°/200d)

≥30

31-42

Bronze coated(g/kg)

0.35-0.65

0.40-0.50

Cu (%)

97-99

98.6-99.2

No. of Joints

2

0

Sn (%)

0.5-3.0

0.8-1.40

Adhesion

≥932N/50mm

1496N/50mm

Assay of chemical contents

C

Mn

Si

P

S

0.70-0.72

0.5-0.60

0.17-0.30

0.006-0.015

0.005-0.017

Surface Quality

Coating Smooth and uniform

conform





We export and supply high quality Tyre Bead Wire at a reasonable price. Tyre Bead Wire is a copper/ bronze coated wire and its main function is to act as reinforcement and it helps to get a proper grip of the Tyre on the rim. Tyre Breed Wire has various features of high strength and good flexibility. The type of tyre and structure of bead rings used, determine the size of bead wire. Tyre Beed Wire is applicable at various industries.
