Automobiles Annealed Steel Wire With Advanced Technology
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Tensile Strength (Mpa): | 1850-1950 | Elongation At Break (%): | 5.5-6.5 |
|---|---|---|---|
| Diameter(mm): | 2.59-2.60 | Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles |
| Feature: | Bronze Coated, Durable, High Tensile, Rustproof, Waterproof | Torsion(360°/100d): | 19-23 |
| Bronze Coated(g/kg): | 0.19-0.24 | Straightness(mm/3m): | 200-500 |
| High Light: | annealed wire,high tensile steel wire,coated steel wire |
||
Automobiles Annealed Steel Wire With Advanced Technology
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ2.6mmHT |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
2.6±0.02 |
2.59-2.60 |
|||
|
Tensile strength (Mpa) |
≥1700 |
1850-1950 |
|||
|
Elongation at break (%) |
≥5 |
5.5-6.5 |
|||
|
Torsion(360°/100d) |
≥15 |
19-23 |
|||
|
Bronze coated(g/kg) |
0.10-0.30 |
0.19-0.24 |
|||
|
Straightness(mm/3m) |
≤600 |
200-500 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
Competitive advantage:
- Coating Smooth and uniform
- Advanced technology
- Competitive price and quality
