Coated Steel Tyre Bead Wire

Large Image : Coated Steel Tyre Bead Wire Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Shengda
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	20 MT
Packaging Details:	Z2
Delivery Time:	With 20 days after confirmed purchase order
Payment Terms:	L/C at sight ,T/T in advance,D/P at sight
Supply Ability:	Monthly 6000 Mt

Contact Now

Detailed Product Description

Application:	Automobiles, Planes, Vehicles	Feature:	Rustproof, Durable, Waterproof, Bronze Coated
Product Name:	Tire Bead Wire	OEM/ODM:	Yes
Standard:	AISI,ASTM,GB,JIS	Steel Grade:	70#,72#,80#,82#
High Light:	copper plated steel wire , tyre steel wire , tire steel wire

Coated Steel Tyre Bead Wire

Number of technical certification

High material and Advanced technology

High productivity

Steel grade:70#,72#,80#,82#

Standard: AISI,ASTM,GB,JIS

Descrition:

Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.

Specifications:

Description	BEAD WIRE		Reference		GB/T14450- 2008		Diameter		Φ0.965mmHT
Item			Standard				Result
Diameter(mm)			0.965±0.02				0.945-0.980
Tensile strength (Mpa)			≥2100				2150-2300
Yield ratio (%)			92.0-95.0				92.7-93.9
Elongation at break (%)			≥5				7.2 -8.8
Torsion (360°/200d)			≥28				30-40
Residual torsion (°/9m)			≯360				90-120
Bronze coated(g/kg)			0.35-0.65				0.40-0.52
Cu (%)			≥97				98.3-99.2
Sn (%)			0.5-3.0				0.80-1.70
Straightness (mm/3m)			≤400				120-400
Adhesion (N/50mm)			≥932				1255
Surface Quality			Coating Smooth and uniform				conform
Assay of chemical contents
C		Mn		Si		P		S
0.70-0.72		0.50-0.60		0.17-0.30		0.006-0.016		0.005-0.018
