Durable 1mm Brass Coated Steel Wire Rope With High Copper 0.49g/kg Customized

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Durable 1mm Brass Coated Steel Wire Rope With High Copper 0.49g/kg Customized Get Best Price

Product Details:
Place of Origin: China
Brand Name: Shengda
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 20 MT
Packaging Details: Z2
Delivery Time: With 20 days after confirmed purchase order
Payment Terms: L/C at sight ,T/T in advance,D/P at sight
Supply Ability: Monthly 6000 Mt
Detailed Product Description
Bronze Coated(g/kg): 0.41-0.49 Elongation At Break (%): 5.0-6.0
Surface Quality: Coating Smooth And Uniform Tensile Strength (Mpa): 1910-2030
Torsion(360°/100d): 31-39 Application: Bike, Bicycle, Automobiles, Motorcycles, Planes, Vehicles
Feature: Rustproof, Durable, Waterproof, Bronze Coated
High Light:

tire bead wire

,

copper clad steel wire

,

coated steel wire

Durable 1mm Brass Coated Steel Wire Rope With High Copper 0.49g/kg Customized





  • Superior quality
  • High copper 0.49g/kg
  • Moisture proof packing
  • Steel grade:70#,72#,80#,82#
  • Standard: AISI,ASTM,GB,JIS





Description:



Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.





Brass Coated Steel Wire is Hose wire ,also called steel wire for hose reinforcement, brass-plated steel wire, rubber tube wire, or brass rubber tube wire. It is used as the reinforcement layer of the rubber hose.





Tyre Bead Wire is a carbon bronze coated steel wire used in all tires. The main function of bead wire is to hold the tire on the rim and to resist the action of the inflated pressure, which constantly tries to force it off.The bead is the crucial link through which the vehicle load is transferred from rim to the tire. It significantly affects the safety, strength, and the durability of tires.





Our offered Tire Bead Wire range is widely used in automobile industry, it act as reinforcement and helps to get a proper grip on tyres.

  • Normal Tensile: 0.78 mm, 0.89 mm, .0.95mm 0.965 mm, 1.55mm1.65 mm,1.8mm 2.0 mm, 2.2 mm
  • High Tensile:0.78mmHT 0.89 mmHT, 0.95 mmHT, 0.965mmHT1.295 mmHT, 1.40 mmHT, 1.55 mmHT, 1.60 mmHT, 1.83 mmHT



Applications



  • Reinforcement of all types of tyres such as trucks, buses, cars, motorcycles,   bicycles etc.
  •  use in  rubber



Specifications:



Description

BEAD  WIRE

Reference

GB/T14450- 2008

Diameter

Φ1.0mm

Item

Standard

Result

Diameter(mm)

1.0±0.02

0.99-1.01

Tensile strength (Mpa)

≥1900

1910-2030

Elongation at break (%)

≥5

5.0-6.0

Torsion(360°/100d)

≥25

31-39

Bronze coated(g/kg)

0.30-0.75

0.41-0.49

Straightness(mm/3m)

≤500

190-400

Surface Quality

Coating Smooth and uniform

conform
