Rustproof Φ2.3mm Steel Bead Wire , Brass Coated Steel wire

Large Image : Rustproof Φ2.3mm Steel Bead Wire , Brass Coated Steel wire Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Shengda
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	20 MT
Packaging Details:	Z2
Delivery Time:	With 20 days after confirmed purchase order
Payment Terms:	L/C at sight ,T/T in advance,D/P at sight
Supply Ability:	Monthly 6000 Mt

Contact Now

Detailed Product Description

Torsion(360°/100d):	28-31	Tensile Strength (Mpa):	1700-1740
Elongation At Break (%):	5.5-6.5	Bronze Coated(g/kg):	0.19-0.24
Diameter(mm):	2.29-2.30	Surface Quality:	Coating Smooth And Uniform
Straightness:	200-500	Application:	Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles
Feature:	Bronze Coated, Durable, Normal Tensile, Rustproof, Waterproof
High Light:	tire bead wire , mild steel wire , copper clad steel wire

Rustproof Φ2.3mm Steel Bead Wire , Brass Coated Steel wire

High material

Advanced technology

Multiple payment and Transportation

Description:

Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.

Specifications:

Description	BEAD WIRE	Reference	GB/T14450- 2008	Diameter	Φ2.3mm
Item		Standard		Result
Diameter(mm)		2.3±0.02		2.29-2.30
Tensile strength (Mpa)		≥1500		1700-1740
Elongation at break (%)		≥5		5.5-6.5
Torsion(360°/100d)		≥20		28-31
Bronze coated(g/kg)		0.10-0.30		0.19-0.24
Straightness(mm/3m)		≤600		200-500
Surface Quality		Coating Smooth and uniform		conform
