Torsion(360°/100d): | 25-29 | Tensile Strength (Mpa): | 1700-1740 |
---|---|---|---|
Elongation At Break (%): | 5.5-6.5 | Bronze Coated(g/kg): | 0.19-0.24 |
Diameter(mm): | 2.59-2.62 | Surface Quality: | Coating Smooth And Uniform |
Straightness (mm/3m): | 200-500 | Elongation At Break(%): | 5.5-6.5 |
Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles | Feature: | Bronze Coated, Durable, Normal Tensile, Rustproof, Waterproof |
High Light: | tire bead wire,mild steel wire,copper clad steel wire |
Durable Φ2.6mm Tire Steel Bead Wire Bronze Coated For Bicycle / Bike
1. Elongation at break (6.5%)
2. Copper coated smoothly
3. Quick delivery time
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ2.6mm |
Item |
Standard |
Result |
|||
Diameter(mm) |
2.6±0.02 |
2.59-2.62 |
|||
Tensile strength (Mpa) |
≥1500 |
1700-1740 |
|||
Elongation at break (%) |
≥5 |
5.5-6.5 |
|||
Torsion(360°/100d) |
≥20 |
25-29 |
|||
Bronze coated(g/kg) |
0.10-0.30 |
0.19-0.24 |
|||
Straightness(mm/3m) |
≤600 |
200-500 |
|||
Surface Quality |
Coating Smooth and uniform |
conform |
