Torsion(360°/100d): | 18-25 | Tensile Strength (Mpa): | 1700-1740 |
---|---|---|---|
Bronze Coated(g/kg): | 0.19-0.24 | Diameter(mm): | 2.29-2.30 |
Surface Quality: | Coating Smooth And Uniform | Straightness (mm/3m): | 200-500 |
Elongation At Break(%): | 5.5-6.5 | Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles |
Feature: | Bronze Coated, Durable, Normal Tensile, Rustproof, Waterproof | ||
High Light: | carbon steel wire,bead wire tire,high carbon steel wire |
Φ3.0mm Bicycle Tyre Steel Bead Wire ,Automatic Computer Control System
Elongation at break (6.0%)
Automatic computer control system
Multiple payment
Description:.
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ3.0mm |
Item |
Standard |
Result |
|||
Diameter(mm) |
2.3±0.02 |
2.29-2.30 |
|||
Tensile strength (Mpa) |
≥1500 |
1700-1740 |
|||
Elongation at break (%) |
≥5 |
5.5-6.5 |
|||
Torsion(360°/100d) |
≥15 |
18-25 |
|||
Bronze coated(g/kg) |
0.10-0.30 |
0.19-0.24 |
|||
Straightness(mm/3m) |
≤600 |
200-500 |
|||
Surface Quality |
Coating Smooth and uniform |
conform |
