Product Details:
Payment & Shipping Terms:
|
Tensile Strength (Mpa): | 1920-2100 | Elongation At Break (%): | 7.2 -8.8 |
---|---|---|---|
Bronze Coated(g/kg): | 0.40-0.52 | Diameter(mm): | 0.945-0.985 |
Yield Ratio (%): | 92.7-93.9 | Surface Quality: | Coating Smooth And Uniform |
Torsion(360°/200d): | 30-40 | Straightness (mm/3m): | 120-400 |
Cu(%): | 98.3-99.2 | Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles |
Feature: | Bronze Coated, Durable, Rustproof, Waterproof | ||
High Light: | carbon steel wire,bead wire tire,high carbon steel wire |
Diameter 0.965MM Tyre Steel Bead Wire With High Tensile For Bicycle
2100mpa tensile strength
Adhesion 1255N/50mm
Competitive price and quality
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ0.965mm |
||||
Item |
Standard |
Result |
|||||||
Diameter(mm) |
0.965±0.02 |
0.945-0.985 |
|||||||
Tensile strength (Mpa) |
≥1850 |
1920-2100 |
|||||||
Yield ratio (%) |
92.0-95.0 |
92.7-93.9 |
|||||||
Elongation at break (%) |
≥5 |
7.2 -8.8 |
|||||||
Torsion (360°/200d) |
≥28 |
30-40 |
|||||||
Residual torsion (°/9m) |
≯360 |
90-120 |
|||||||
Bronze coated(g/kg) |
0.35-0.65 |
0.40-0.52 |
|||||||
Cu (%) |
≥97 |
98.3-99.2 |
|||||||
Sn (%) |
0.5-3.0 |
0.80-1.70 |
|||||||
Straightness (mm/3m) |
≤400 |
120-400 |
|||||||
Adhesion (N/50mm) |
≥932 |
1255 |
|||||||
Surface Quality |
Coating Smooth and uniform |
conform |
|||||||
Assay of chemical contents |
|||||||||
C |
Mn |
Si |
P |
S |
|||||
0.70-0.72 |
0.50-0.60 |
0.17-0.30 |
0.006-0.016 |
0.005-0.018 |
