High Tensile Annealed Steel Wire 2060Mpa With Brass Coated
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Elongation At Break (%): | 5.0-6.0 | Diameter(mm): | 1.63-1.67ｍｍ |
|---|---|---|---|
| Breaking Force (Mpa): | 2050-2150 | Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles |
| Feature: | Bronze Coated, Durable, High Tensile, Rustproof | Yield Ratio(%): | 85.4-87.6 |
| Bronze Coated(g/kg): | 0.32-0.36 | Torsion(360°/100d): | 29-35 |
| High Light: | annealed steel,annealed wire,annealing of steel |
||
High Tensile Annealed Steel Wire 2060Mpa With Brass Coated
Quick Detail:
- Type: Bead wire
- Diameter:1.63-1.67ｍｍ
- Breaking force (Mpa):2050-2150
- Elongation at break(%):5.0-6.0
- Yield ratio(%):85.4-87.6
- Bronze coated(g/kg):0.32-0.36
- Torsion(360°/100d):29-35
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ 1.65mmHT |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.65± 0.02 |
1.63-1.67 |
|||
|
Breaking force (Mpa) |
≥2050 |
2050-2150 |
|||
|
Elongation at break(%) |
≥5.0 |
5.0-6.0 |
|||
|
Yield ratio(%) |
≥85 |
85.4-87.6 |
|||
|
Torsion(360°/100d) |
≥25 |
29-35 |
|||
|
Bronze coated(g/kg) |
0.20-0.40 |
0.32-0.36 |
|||
|
Sn (%) |
0.3-3.0 |
1.7 |
|||
|
Cu(%) |
≥97 |
98.3 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
Competitive advantage
- 2060mpa high tensile strength
- Coil with Six steel belts fixed
- 6000MT monthly production
