Brass Plated Cold Drawn Steel Wire Φ0.89mm , Yield Rate 94%
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles | Feature: | Bronze Coated, Durable, Rustproof, Waterproof |
|---|---|---|---|
| Diameter(mm): | 0.87-0.91 | Break Force (N): | 1990-2160 |
| Yield Rate (%): | 93.3-94.9 | Elongation At Break(%): | 7.0-8.5 |
| Torsion(360°/200d): | 59-75 | Straightness (mm/3m): | 180-460 |
| High Light: | Cold Drawn Steel Wire,Tire Bead Wire |
||
Brass Plated Cold Drawn Steel Wire Φ0.89mm , Yield Rate 94%
1. Great break force
2. Yield rate 94%
3. Quick delivery time
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ0.89mm |
||||
|
Item |
Standard |
Result |
|||||||
|
Diameter(mm) |
0.89±0.02 |
0.87-0.91 |
|||||||
|
Break force (N) |
≥1950 |
1990-2160 |
|||||||
|
Yield rate (%) |
93.0-96.0 |
93.3-94.9 |
|||||||
|
Elongation at break(%) |
≥5.0 |
7.0-8.5 |
|||||||
|
Torsion(360°/200d) |
≥50 |
59-75 |
|||||||
|
Residual torsion (° /9m) |
≯360 |
90-120 |
|||||||
|
Bronze coated(g/kg) |
0.35-0.65 |
0.40-0.51 |
|||||||
|
Sn (%) |
0.5-3.0 |
0.7-1.5 |
|||||||
|
Straightness (mm/3m) |
≤500 |
180-460 |
|||||||
|
Adhesion (N/50mm) |
≥1200 |
1242 |
|||||||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||||||
|
Assay of chemical contents |
|||||||||
|
C |
Mn |
Si |
P |
S |
|||||
|
0.70-0.72 |
0.50-0.60 |
0.17-0.26 |
0.006-0.016 |
0.005-0.018 |
|||||
