High Tensile Cold Drawn Steel Wire , Bronze Coated Bead Wire
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Tensile Strength (Mpa): | 2150-2250 | Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles |
|---|---|---|---|
| Feature: | Bronze Coated, Durable, Rustproof, Waterproof | Diameter(mm): | 0.99-1.01 |
| Elongation At Break (%): | 5.0-6.0 | Torsion(360°/100d): | 31-39 |
| Bronze Coated(g/kg): | 0.41-0.49 | Straightness(mm/3m): | 190-400 |
| High Light: | cold drawn wire,cold drawing steel,cold drawing of wire |
||
High Tensile Cold Drawn Steel Wire , Bronze Coated Bead Wire
First-class material
High tensile 2250map
Elongation at break 6.0%
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ1.0mmHT |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.0±0.02 |
0.99-1.01 |
|||
|
Tensile strength (Mpa) |
≥2100 |
2150-2250 |
|||
|
Elongation at break (%) |
≥5 |
5.0-6.0 |
|||
|
Torsion(360°/100d) |
≥25 |
31-39 |
|||
|
Bronze coated(g/kg) |
0.30-0.75 |
0.41-0.49 |
|||
|
Straightness(mm/3m) |
≤500 |
190-400 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
