Tyre Cold Drawn Steel Wire Φ1.65mm , Coil With Six Steel Belts Fixed
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Yield Ratio: | 85.4-87.6 | Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles |
|---|---|---|---|
| Feature: | Bronze Coated, Durable, Normal Tensile, Rustproof, Waterproof | Diameter(mm): | 1.63-1.67 |
| Breaking Force (Mpa): | 1850-1900 | Elongation At Break(%): | 5.0-6.0 |
| Torsion(360°/100d): | 29-35 | Bronze Coated(g/kg): | 0.32-0.36 |
| High Light: | cold drawn wire,cold drawing steel,cold drawing of wire |
||
Tyre Cold Drawn Steel Wire Φ1.65mm , Coil With Six Steel Belts Fixed
Yield ratio 87.6%
Superior quality with high material
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ 1.65mm |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.65± 0.02 |
1.63-1.67 |
|||
|
Breaking force (Mpa) |
≥1850 |
1850-1900 |
|||
|
Elongation at break(%) |
≥5.0 |
5.0-6.0 |
|||
|
Yield ratio(%) |
≥85 |
85.4-87.6 |
|||
|
Torsion(360°/100d) |
≥25 |
29-35 |
|||
|
Bronze coated(g/kg) |
0.20-0.40 |
0.32-0.36 |
|||
|
Sn (%) |
0.3-3.0 |
1.7 |
|||
|
Cu(%) |
≥97 |
98.3 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
