Diameter 1.2mm Copper Clad Steel Wire Tyre , 1860Mpa Breaking Force
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles | Feature: | Bronze Coated, Durable, Rustproof, Waterproof |
|---|---|---|---|
| Diameter(mm): | 1.17-1.20 | Breaking Force (Mpa): | 1800-1860 |
| Elongation At Break(%): | 5.0-6.0 | Yield Ratio(%): | 85.4-87.6 |
| Torsion(360°/100d): | 29-35 | Bronze Coated(g/kg): | 0.68-1.00 |
| Straightness(mm/3m): | 200-500 | Surface Quality: | Coating Smooth And Uniform |
| High Light: | copper coated steel wire,coated steel wire,low carbon steel wire |
||
Diameter 1.2mm Copper Clad Steel Wire Tyre , 1860Mpa Breaking Force
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
Description | BEAD WIRE | Reference | GB/T14450- 2008 | Diameter | Φ 1.20mm |
Item | Standard | Result | |||
Diameter(mm) | 1.17-1.20 | 1.17-1.20 | |||
Breaking force (Mpa) | ≥1800 | 1800-1860 | |||
Elongation at break(%) | ≥5.0 | 5.0-6.0 | |||
Yield ratio(%) | ≥80 | 85.4-87.6 | |||
Torsion(360°/100d) | ≥26 | 29-35 | |||
Bronze coated(g/kg) | 0.65-1.2 | 0.68-1.00 | |||
Sn (%) | 0.3-3.0 | 1.7 | |||
Cu(%) | ≥97 | 98.3 | |||
Straightness(mm/3m) | ≤600 | 200-500 | |||
Surface Quality | Coating Smooth and uniform | conform | |||
Competitive advantage:
- First-class material
- High tensile 2250map
- Elongation at break 6.0%
