0.78mm Copper Clad Steel Wire For Vehicles , Coating Smooth Surface

Large Image : 0.78mm Copper Clad Steel Wire For Vehicles , Coating Smooth Surface Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Shengda
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	20 MT
Packaging Details:	Z2
Delivery Time:	With 20 days after confirmed purchase order
Payment Terms:	L/C at sight ,T/T in advance,D/P at sight
Supply Ability:	Monthly 6000 Mt

Contact Now

Detailed Product Description

Application:	Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles	Feature:	Bronze Coated, Durable, Rustproof, Waterproof
Diameter(mm):	0.79	Surface Quality:	Coating Smooth And Uniform
Straightness:	450	Tensile(Mpa):	2156
Elongation(%):	8.8	Torsion(360°/200d):	59
High Light:	copper coated steel wire , coated steel wire , low carbon steel wire

0.78mm Copper Clad Steel Wire For Vehicles , Coating Smooth Surface

1. Copper coated

2. Coating Smooth and uniform

3. High tensile

Description:

Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.

Specifications:

Description	BEAD WIRE		Reference		GB/T14450- 2008		Diameter		Φ0.78mm
Item			Standard				Result
Diameter(mm)			0.78±0.02				0.79
Surface Quality			Coating Smooth and uniform				conform
Straightness			The property of a 3 meter long wire to be straightness at a 600mm-distance of between Straight parallel lines				450
Tensile(Mpa)			≥1850				2156
Elongation(%)			≥5				8.8
Torsion(360°/200d)			≥50				59
Cu (%)			≥97				99.3
Yield Rate %			＞80				90.1
Sn (%)			0.3-3.0				0.70
Adhesion			≥685N/50mm				948N/50mm
Assay of chemical contents
C		Mn		Si		P		S
0.71-1.2		0.5-0.60		0.17-0.28		0.006-0.018		0.005-0.019
