Rustproof Copper Clad Steel Wire With High Copper 0.49g/kg
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles | Feature: | Bronze Coated, Durable, High Tensile, Rustproof, Waterproof |
|---|---|---|---|
| Diameter(mm): | 0.99-1.01 | Tensile Strength (Mpa): | 1910-2030 |
| Elongation At Break (%): | 5.0-6.0 | Torsion(360°/100d): | 31-39 |
| Bronze Coated(g/kg): | 0.70-1.0 | Straightness(mm/3m): | 190-400 |
| High Light: | copper coated steel wire,coated steel wire,low carbon steel wire |
||
Rustproof Copper Clad Steel Wire With High Copper 0.49g/kg
Superior quality
High copper 0.49g/kg
Moisture proof packing
Descrition:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ1.0mm |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.0±0.02 |
0.99-1.01 |
|||
|
Tensile strength (Mpa) |
≥1900 |
1910-2030 |
|||
|
Elongation at break (%) |
≥5 |
5.0-6.0 |
|||
|
Torsion(360°/100d) |
≥25 |
31-39 |
|||
|
Bronze coated(g/kg) |
0.68-1.2 |
0.70-1.0 |
|||
|
Straightness(mm/3m) |
≤500 |
190-400 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
