Φ1.55mm Tire Copper Clad Steel Wire , Bronze coated 0.30-1.5g/kg
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles | Feature: | Durable, Normal Tensile, Rustproof, Waterproof |
|---|---|---|---|
| Diameter(mm): | 1.53-1.56 | Tensile Strength (Mpa): | 1870-1980 |
| Elongation At Break (%): | 5.0-6.0 | Torsion(360°/100d): | 29-38 |
| Bronze Coated(g/kg): | 1.2 | Straightness(mm/3m): | 200-500 |
| High Light: | copper coated steel wire,coated steel wire,low carbon steel wire |
||
Φ1.55mm Tire Copper Clad Steel Wire , Bronze coated 0.30-1.5g/kg
Bronze coated 0.27g/kg
Superior quality
Reasonable price
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ1.55mm |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.55±0.02 |
1.53-1.56 |
|||
|
Tensile strength (Mpa) |
≥1850 |
1870-1980 |
|||
|
Elongation at break (%) |
≥5 |
5.0-6.0 |
|||
|
Torsion(360°/100d) |
≥25 |
29-38 |
|||
|
Bronze coated(g/kg) |
0.30-1.5 |
1.2 |
|||
|
Straightness(mm/3m) |
≤600 |
200-500 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
