2060mpa high tensile strength Steel Bead Wire , Bicycle Bronze Coated 1.55mm
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Diameter(mm): | 1.53-1.56 | Elongation At Break (%): | 5.0-6.0 |
|---|---|---|---|
| Tensile Strength (Mpa): | 2040-2060 | Torsion(360°/100d): | 29-38 |
| Bronze Coated(g/kg): | 0.27 | Straightness(mm/3m): | 200-500 |
| High Light: | tyre bead wire,Tyre Steel Wire,Tire Steel Wire |
||
2060mpa high tensile strength Steel Bead Wire , Bicycle Bronze Coated 1.55mm
- Steel grade:70#,72#,80#,82#
- Standard: AISI,ASTM,GB,JIS
- 2060mpa high tensile strength
- Specialty in bead wire
- 6000MT monthly production
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Tyre Bead Wire is a copper/ bronze coated wire and its main function is to act as reinforcement and it helps to get a proper grip of the Tyre on the rim.The bead is the crucial link through which the vehicle load is transferred from rim to the tire. It significantly affects the safety, strength, and the durability of tires.
Following basic properties are required in the making of tyre bead wire:
- Combination of high tensile and ductility,
- Uniform and appropriate bronze coating,
- Strong adhesion of wire to the rubber,
- Consistency in physical properties
- Uniform winding and proper coil dimensions.
Our range of Tyre Bead Steel Wire includes:
- High Tensile:0.78mmHT 0.89 mmHT, 0.95 mmHT, 0.965mmHT1.295 mmHT, 1.40 mmHT, 1.55 mmHT, 1.60 mmHT, 1.83 mmHT
- Normal Tensile: 0.78 mm, 0.89 mm, .0.95mm 0.965 mm, 1.55mm1.65 mm,1.8mm 2.0 mm, 2.2 mm
Applications
- Reinforcement of all types of tyres such as trucks, buses, cars, motorcycles, bicycles etc.
- use in rubber
Features:
- Precisely engineered
- Fine finish
- Tensile strength
Specifications:
Description | BEAD WIRE | Reference | GB/T14450- 2008 | Diameter | Φ1.55mmHT |
Item | Standard | Result | |||
Diameter(mm) | 1.55±0.02 | 1.53-1.56 | |||
Tensile strength (Mpa) | ≥2050 | 2040-2060 | |||
Elongation at break (%) | ≥5 | 5.0-6.0 | |||
Torsion(360°/100d) | ≥25 | 29-38 | |||
Bronze coated(g/kg) | 0.15-0.30 | 0.27 | |||
Straightness(mm/3m) | ≤600 | 200-500 | |||
Surface Quality | Coating Smooth and uniform | conform | |||
