Product Details:
Payment & Shipping Terms:
|
Diameter(mm):: | 0.94-0.96 | Straightness:: | 120-400 |
---|---|---|---|
Adhesion:: | 1496N/50mm | Tensile Strength (Mpa):: | 2150-2230 |
Elongation At Break (%): | 8.5-9.2 | Yield Ratio(%): | 93.4-94.9 |
Bronze Coated(g/kg): | 0.40-0.50 | Cu(%): | 98.6-99.2 |
Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles | Feature: | Bronze Coated, Durable, High Tensile, Rustproof |
High Light: | low carbon steel rod,carbon steel wire rod,tensile strength of low carbon steel |
High Tensile Bronze Coated Low Carbon Steel Wire Φ0.95mm For Automobiles
High tensile 2230 mpa
Inside the waterproof packing
6000MT monthly production
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ0.95mmHT |
||||
Item |
Standard |
Result |
|||||||
Diameter(mm) |
0.94-0.97 |
0.94-0.96 |
|||||||
Straightness |
≤400 |
120-400 |
|||||||
Yield ratio |
92.0-95.0 |
93.4-94.9 |
|||||||
Tensile(Mpa) |
≥2100 |
2150-2230 |
|||||||
Elongation(%) |
≥5 |
8.5-9.2 |
|||||||
Torsion(360°/200d) |
≥30 |
31-42 |
|||||||
Bronze coated(g/kg) |
0.35-0.65 |
0.40-0.50 |
|||||||
Cu (%) |
97-99 |
98.6-99.2 |
|||||||
No. of Joints |
2 |
0 |
|||||||
Sn (%) |
0.5-3.0 |
0.8-1.40 |
|||||||
Adhesion |
≥932N/50mm |
1496N/50mm |
|||||||
Assay of chemical contents |
|||||||||
C |
Mn |
Si |
P |
S |
|||||
0.70-0.72 |
0.5-0.60 |
0.17-0.30 |
0.006-0.015 |
0.005-0.017 |
|||||
Surface Quality |
Coating Smooth and uniform |
conform |
