High Tensile Bronze Coated Low Carbon Steel Wire Φ0.95mm For Automobiles

All Products

Tire Bead Wire (57)

Steel Bead Wire (19)

Coated Beading Wire (21)

Copper Coated Steel Wire (11)

Annealed Steel Wire (20)

Copper Clad Steel Wire (12)

Tire Steel Wire (39)

Low Carbon Steel Wire (18)

Brass Coated Steel Wire (12)

Cold Drawn Steel Wire (16)

I'm Online Chat Now

Certification

1.Excellent quality, competitive price, good service, timely delivery; 2. No customer complaints

—— Deestone Limited

High Tensile Bronze Coated Low Carbon Steel Wire Φ0.95mm For Automobiles

Large Image : High Tensile Bronze Coated Low Carbon Steel Wire Φ0.95mm For Automobiles Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Shengda
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	20 MT
Packaging Details:	Z2
Delivery Time:	With 20 days after confirmed purchase order
Payment Terms:	L/C at sight ,T/T in advance,D/P at sight
Supply Ability:	Monthly 6000 Mt

Contact Now

Detailed Product Description

Diameter(mm)：:	0.94-0.96	Straightness：:	120-400
Adhesion：:	1496N/50mm	Tensile Strength (Mpa)::	2150-2230
Elongation At Break (%):	8.5-9.2	Yield Ratio(%):	93.4-94.9
Bronze Coated(g/kg):	0.40-0.50	Cu(%):	98.6-99.2
Application:	Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles	Feature:	Bronze Coated, Durable, High Tensile, Rustproof
High Light:	low carbon steel rod , carbon steel wire rod , tensile strength of low carbon steel

High Tensile Bronze Coated Low Carbon Steel Wire Φ0.95mm For Automobiles

High tensile 2230 mpa

Inside the waterproof packing

6000MT monthly production

Description:

Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.

Specifications:

Description	BEAD WIRE		Reference		GB/T14450- 2008		Diameter		Φ0.95mmHT
Item			Standard				Result
Diameter(mm)			0.94-0.97				0.94-0.96
Straightness			≤400				120-400
Yield ratio			92.0-95.0				93.4-94.9
Tensile(Mpa)			≥2100				2150-2230
Elongation(%)			≥5				8.5-9.2
Torsion(360°/200d)			≥30				31-42
Bronze coated(g/kg)			0.35-0.65				0.40-0.50
Cu (%)			97-99				98.6-99.2
No. of Joints			2				0
Sn (%)			0.5-3.0				0.8-1.40
Adhesion			≥932N/50mm				1496N/50mm
Assay of chemical contents
C		Mn		Si		P		S
0.70-0.72		0.5-0.60		0.17-0.30		0.006-0.015		0.005-0.017
Surface Quality			Coating Smooth and uniform				conform
