High Tensile Low Carbon Steel Wire For Bicycle / Bike Tires Rims
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Diameter(mm)：: | Φ2.3mmHT | Straightness：: | 200-500 |
|---|---|---|---|
| Tensile Strength (Mpa）：: | 1850-1950 | Elongation At Break (%): | 5.5-6.5 |
| Torsion(360°/100d): | 28-31 | Bronze Coated(g/kg): | 0.19-0.24 |
| Application: | Automobiles, Bicycle, Bike, Motorcycles, Planes, Vehicles | Feature: | Bronze Coated, Durable, High Tensile, Rustproof |
| High Light: | mild steel wire,copper clad steel wire,low carbon steel rod |
||
High Tensile Low Carbon Steel Wire For Bicycle / Bike Tires Rims
All Patents for production
Advanced technology
Competitive price and quality
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles,motorcycles,planes as well as other vehicles.It’s the pivotal material of tire,which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ2.3mmHT |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
2.3±0.02 |
2.29-2.30 |
|||
|
Tensile strength (Mpa) |
≥1700 |
1850-1950 |
|||
|
Elongation at break (%) |
≥5 |
5.5-6.5 |
|||
|
Torsion(360°/100d) |
≥20 |
28-31 |
|||
|
Bronze coated(g/kg) |
0.10-0.30 |
0.19-0.24 |
|||
|
Straightness(mm/3m) |
≤600 |
200-500 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
